TEST ALIGNMENT TARGET

OnsiteBIM Alignment Target (ID 12)

Aim your camera at this test target in OnsiteBIM to instantly align loaded 3D BIM models on site.

OnsiteBIM Alignment Target (5.0 cm × 5.0 cm)
OnsiteBIM Alignment Target ID 12 (5cm x 5cm out-to-out black border)
OnsiteBIM Alignment Target — ID 12
50.0 mm × 50.0 mm Out-to-Out Black Border
Aim Camera at Screen: Open OnsiteBIM, load a model, and point your camera at this target to test auto-alignment instantly.
Display Scale Disclaimer: This target is supposed to be exactly 50 mm × 50 mm (5 cm × 5 cm) out-to-out. If your display shows it at anything other than this specific dimension, it will affect the test model placement in the app. For guaranteed physical scale precision on jobsites, use the Alignment Target Generator.
Revit Toolkit on GitHub
How To Test In 3 Steps
1
BIM / CAD Reference: In your 3D model, place the Alignment Target origin marker at a designated reference point (e.g. Column grid or structural footing).
2
Load Model (Device or Cloud): Select and load your 3D model (.ifc, .glb, or .usdz) stored directly on your device or from Google Drive, OneDrive, or Dropbox in OnsiteBIM.
3
Aim at Alignment Target: Point your camera at this screen or a printed target. The target establishes physical placement and orientation, instantly snapping your loaded 3D model into place at 1:1 scale.

Need a Custom ID or Jobsite A4 Sheet?

Generate calibrated 150 mm black border targets with custom tag IDs, metric/imperial scale verification bars, and corner crop marks for construction field printing.

Launch Alignment Target Generator →
